OEM 7700417957A - Hydraulic Steering Pump for RENAULT LAGUNA I (B56_, 556_) 1.6 16V (B568, B561)

OE No:	7700417957A 7700426719 7700431283
HG No:	HGSP0541
Car Series:	France Car
Car Brand:	RENAULT
Car Model:	RENAULT LAGUNA I (B56_, 556_) 1.6 16V (B568, B561)
Warranty:	12 Months

Inquire Now Next Product

Product Description

OE No: 7700417957A 7700426719 7700431283

Applicable Models:

RENAULT

LAGUNA I (B56_, 556_) 1.6 16V (B568, B561) K4M 720,K4M 724 1997-2001

MASTER II Van (FD) 2.2 dCI 90 (FD0G, FD0N, FD2G, FD2N, FD3G, FD3N) G9T 720,G9T 722,G9T 750 1997-2006

MASTER II Van (FD) 2.5 dCi 100 (FD0U, FD0V, FD3U, FD3V, FD8U, FD8V) G9U 754 2003-2010

MEGANE I Coach (DA0/1_) 1.6 16V (DA0B, DA04, DA11) K4M 700,K4M 701,K4M 708,K4M 709 1999-2003

MEGANE I Coach (DA0/1_) 2.0 16V IDE (DA03, DA0P, DA14) F5R 740 1999-2003

SCÉNIC I MPV (JA0/1_, FA0_) 1.6 (JA00, JA16, JA15, JA19, JA1V, JA2B, JA2C, JA0B K4M 700,K4M 706,K4M 707,K4M 776 1999-2003

Structure of the Steering Pump

1. Drive wheel 2. Drive shaft 3. Circlip 4. Oil seal 5. Bearing 6. Pump body 7. Steel ball 8. Pressure switch assembly 9.O type sealing ring 10. Pressure plate 11.Stator 12. Blade 13. Rotor 14. Bolt 15. Pump cover 16. Sealing ring 17. Locating pin 18. Protection blockage 19. Bolt 20. Oil inlet pipe 21.O-shaped sealing ring 22. Valve block 23. Spring 24. Slide valve assembly

The steering pump is the core component of a hydraulic power steering (HPS) system, responsible for supplying high-pressure hydraulic fluid to the steering system, thereby assisting the driver in turning the steering wheel with ease.
